HERTZ MARINE HMX 6.5-TW COAXILS SPEAKERS

HMX 6.5 TW / TC165 (6.5) mm (in.) / 95,6 (3.76) mm (in.) / Hi-end Coax / 150 W / 4 Ohm
HMX 6.5 TW hi-performance marine coaxial speakers, also available in the black option HMX 6.5 TC, features a tone-on-tone stainless steel front mesh matching the grille colour. Coaxial speaker is optimized to perform in infinite baffle, with a solid bass and an outstanding output. The tweeter feature an acoustic lens optimized for best off-axis dispersion and maximized SPL. The UV resistant polypropylene cone co-molded with Santoprene rubber surround together with the basket and grille injected with a Hi-temperature and UV resistant polymer neutralize water, dust and mud. The aramid fiber spider with silicone-insulated lead wires ensures durability and constant performance over time. The high-excursion mobile equipment is driven by a massive magnetic group, to deliver high undistorted sound pressure

TECHNICAL SPECS


Component HI-END COAX
Size mm (in.) 165 (6.5)
Power Handling - Continuous W 75
Power Handling - Peak W 150
Impedance Ohm 4
Depth mm (in.) 95,6 (3.76)
Tweeter diaphragm mm (in.) 36 (1.4)
Woofer Voice Coil Ø mm (in.) 25 (1)
Tweeter Voice Coil Ø mm (in.) 20 (0.8)
Frequency Response Hz 50 ÷ 25k
Woofer Magnet size D x d x h mm (in.) 78,5 x 32 x 17 (3.09 x 1.26 x 0.67)
Tweeter Magnet size D x h mm (in.) 19,7 x 3 (0.78 x 0.12)
Weight of one speaker kg (lb.) 1 (2.2)
Woofer Magnet High density flux ferrite
Tweeter Magnet Neodymium
Cone Polypropylene with UV inhibitors
Dome PEI
Xmech mm (in.) ±6,65 (0.26)

ELECTRO - ACOUSTIC SPECS

D mm 125
Re Ohm 3,5
Fs Hz 65
Le mH 0,53
Vas I 8,8
Mms g 14
Cms mm/N 0,4
BL T*m 5,2
Qts 0,7
Qes 0,75
Qms 11,5
Spl dB 89
Electro-acoustic Specs
