Specifications
Product Highlights
Size & Weight
WEIGHT
6.17 lb

DIMENSIONS (W X H X D)
10.67 x 6.73 x 9.72"

General Features
PRE OUT
5 V 3 Pre (Front LR / Rear LR / Sub LR)

TIME ALIGNMENT
Yes

FIRMWARE UPGRADABILITY
Yes

OUTPUT POWER
55 W x4

USB
Yes (Type-C x 1, REAR)

EQUALIZER
14-band Equalizer and 8-band Parametric Equalizer

REAR VIEW CAMERA IN
Rear/Input 1/Input 2

ALBUM ARTWORK INDICATION
Yes

Tuner Features
PRESET
FM18/AM12

AUTO MEMORY
BTM

RDS / EON
Yes (RBDS)

Bluetooth Profile
HFP 1.5
Yes (1.7.1)

AVRCP
Yes (1.6.1)

A2DP
Yes (1.3.1)

PBAP
Yes (1.1)

Bluetooth Features
CALL VOLUME LEVEL CONTROL
Yes

RING VOLUME LEVEL CONTROL
Yes

EXTERNAL MICROPHONE
Supplied

SPEED DIAL
Yes (6 memories)

SIGNAL STRENGTH INDICATION
Yes

ALPHABETICAL PHONEBOOK SORTING
Yes

LAST DIALED CALL
Yes (select from the dialed call history)

RECENT CALLS (# OF)
Yes

PHONE BATTERY LEVEL REMINDER
Yes

PHONEBOOK ACCESS VIA PBAP
Yes

Bluetooth Audio Features
META DATA INDICATION
Yes

PAUSE (BLUETOOTH AUDIO)
Yes

TRACK +/-
Yes

REPEAT CONTROL (AUDIO DEVICE SIDE)
Yes

AUDIO CODEC (BLUETOOTH AUDIO)
SBC/AAC/LDAC

CUE / REV
Yes

SHUFFLE CONTROL (AUDIO DEVICE SIDE)
Yes

AUDIO LEVEL ADJUSTMENT
Yes (–6 dB to +6 dB)

GROUP (FOLDER) +/-
Yes

Panel Design
PANEL DETACHABILITY
Yes (For installation only)

KEY ILLUMINATION
Yes on Front Panel (White)

Monitor(AVC)
SCREEN DIAGONAL (INCH / MM)
10.1 inch / 257 mm

RESOLUTION (DOT)
1280 x 720

CONTRAST RATIO
1,000

LCD TYPE
TFT Active Matrix

SCREEN SIZE (W X H MM)
223.7 x 125.8 (mm)

SCREEN ASPECT
16 : 9

DIMMER
Auto/Manual select

BRIGHTNESS
39.48 cd/ft2

Display Panel
KEY ILLUMINATION
On Front Panel (White)

DIMMER ADJUST
Yes

User Interface
PARKING CONTROL
Yes

TOUCH PANEL
Yes/Capacitive

PARKING LINE ADJUST
Yes

REAR VIEW CAMERA-IN MARKER SETTING
Yes

USB Mass Storage Device Control Feature
USB DEVICE CONTROL (REPEAT)
TRACK/FOLDER/DRIVE

USB DEVICE CONTROL (RESUME PLAY)
Yes

USB DEVICE CONTROL (AUDIO CODEC)
MP3/WMA/WAV/AAC/FLAC/ALAC/DSF/DSDIFF

USB DEVICE CONTROL (SHUFFLE)
OFF/FOLDER/DEVICE

USB DEVICE CONTROL (PAUSE)
Yes

USB DEVICE CONTROL (AUDIO PLAYABLE FILE EXTENSION)
.mp3/.wma/.wav/.m4a/.mp4/.flac/.m4a/.mp4/.dsf/.
